New Yanmar Wheel Loaders


Offering class-leading lift capacity, greater operator visibility and automated controls, Yanmar's new V-Series compact wheel loaders do more in less time and at less cost. The two new loader designs are built around quiet, reliable, fuel-efficient Yanmar diesel engines. For multi-purpose versatility, the V3-6 and V4-6 loaders can be equipped with an optional mechanical Quick-Coupler that fits most skid steer attachments.

A user-friendly design philosophy was focused on the three major elements demanded in wheel loaders for today's highly competitive construction market; ease of operation, versatility and durable on-site performance. These new models also offer a reduced overall height to make them even more compatible with enclosed carrier loading and unloading operations. This lower profile also improves the machine's center of gravity promoting greater stability in the process.

A fully automatic drive mode allows the 3000 kg V3-6 and 3500 kg V4-6 loaders to accelerate smoothly and change gears with no operator input. A fixed speed mode keeps them in low gear regardless of the position of the accelerator pedal. Power comes from Yanmar's highly regarded TNV series engine. This 3-cylinder, watercooled diesel generates 30,3 hp and can propel the V3-6 up to 19 km/h. The V4-6 utilizes a 40,4 hp version of this engine and motivates this loader to a similar maximum speed.

Driving force is transmitted evenly to the ground thanks to a system of rear axle oscillation. Designed for irregular surfaces, this feature reduces operator fatigue and ensures operator control of the equipment. Combined with a full 25 cm of ground clearance on the V3-6 and 30 cm for the V4-6, unlimited access to any and all parts of the jobsite is the routine.

Single lever operation places the bucket on the ground and at the ready. Actual bucket movement is fast, smooth and consistent. Lifting capacity for both loaders is rated at a hefty 2600 kg for the V3-6 and 3380 kg for the larger V4-6.

Forward and reverse loader movement is also activated by a column shifted lever with a safety lock so the loader cannot accidentally travel in the wrong direction. A parking brake is provided to secure a static position for a more stable work platform. This brake can only be released by pulling the prescribed lever thereby enhancing job-site safety.

Source: Yanmar Construction Equipment Co. Ltd.
